QIDI X-Max 3 3D Printer

Add your review

Computers & Office Office Equipment SKU: 520946

Product is rated as #9 in category Computers & Office

Design	9
Software	8.9
Printing	9
Power	9.1

TMC2209 silent driver and CoreXY structure can reduce motion inertia and increase motion speed, providing a low-noise printing experience.
BLTouch sensor’s automatic 16-point bed leveling feature ensures good first-layer adhesion and prevents part distortion.
The chamber has a circulation fan and activated carbon air filter to deliver better printing results and a safe environment.
QIDI slicing software has standard and expert modes, making it easy for beginners to use.
Using an independent heating device, the maximum temperature can reach 65 degrees Celsius.
Printing speed up to 600mm/s, the printing acceleration 20000mm/s², and the extruder flow rate is 35mm3/s.

Description
Specifications
Videos
Price Alert
Price History

Structure

The QIDI X-Max 3 incorporates a TMC2209 silent driver and utilizes a CoreXY structure to improve its overall performance. The TMC2209 driver reduces motion inertia, increasing motion speed and resulting in a quieter printing experience.

Leveling

Including a BLTouch sensor in the QIDI X-Max 3 effectively addresses achieving proper bed leveling. Its automatic 16-point bed leveling feature ensures consistent first-layer adhesion and minimizes part distortion.

Environment

The QIDI X-Max 3 has features to create an optimal printing environment. It includes a circulation fan and an activated carbon air filter. The circulation fan regulates temperature and airflow within the chamber, contributing to improved print quality. Meanwhile, the activated carbon air filter assists in trapping particulates, promoting a cleaner and safer printing environment.

Software

QIDI provides slicing software that caters to users with varying levels of expertise. The software offers both standard and expert modes, accommodating beginners and experienced users alike. The standard mode simplifies the slicing process, making it accessible to those new to 3D printing, while the expert mode offers advanced options for more experienced users.

Performance

The QIDI X-Max 3 offers noteworthy technical specifications. Its independent heating device allows users to reach a maximum temperature of 65 degrees Celsius, expanding the range of compatible filament materials. Additionally, the printer demonstrates impressive speed capabilities with a maximum printing speed of up to 600mm/s and a printing acceleration of 20000mm/s². The extruder’s flow rate of 35mm³/s further enhances its efficiency.

9.3Expert Score

Gizcoupon Review

QIDI X-Max 3 offers a large build volume and dual extruders but comes at a higher cost and with size limitations.

Design

Software

8.9

Printing

Power

9.1

PROS

Large build volume
Dual extruders for multi-material prints
Sturdy construction
User-friendly interface

CONS

High initial cost
Requires assembly
Limited to proprietary filament
Bulky size

Specification: QIDI X-Max 3 3D Printer

General	Brand: QIDI Type: 3D Printer Model: X-Max 3 Color: Black
Specification	Technology: FDM Build Volume: 325325315mm Printing Speed: ≤600mm/s Extruder Flow: 35mm³/s Extruder Temp: ≤350°C Hotend (Included): Copper alloy nozzle hotend for Common materials; Hardened steel nozzle hotend for Abrasive materials Auxiliary Part Cooling Fan: Yes Chamber Temperature Control: 65 Celsius Independent Chamber Heating Chamber Circulation Fan with Activated Carbon Air Filter: Yes Screen: 5.0 inch, 800*480 touchscreen Seal Print: Dryer Box + Desiccant Connection Options: 150M 2.4G WiFi; USB Flash Drive/Ethernet Cable Rated Power: 900W Recommended Filament: PAHT-CF, PET-CF, PA12-CF Compatible Filament: PLA, ABS, ASA, PETG, TPU, PC, UltraPA, Nylon, etc. Structure: CoreXY Z-axis: Double Z axis X-axis: High-grade hardness steel linear hollow optical axis Firmware: Klipper Printing Acceleration: 20000mm/s² Printing Accuracy: ±0.1 mm Filament Diameter: 1.75mm Bed Leveling: Automatic Leveling Extruder Transmission Ratio: 9.5:1 Hot End: Ceramic Heating Core Extruder: High-flow Direct Drive Extruder Nozzle Diameter: 0.4mm (0.2,0.6,0.8mm Optional) Hot Bed Temperature: ≤120 Celsius Printing Plate: Double-Sided Flexible Magnetic HF Plate Filament Detection: Yes Resonance Compensation: Yes Pressure Advance: Yes Voltage: 100-240VAC, 50/60Hz Main Processor: Cortex-A53, 64-bit Processor, 1.5Ghz,8G-EMMC,1G DDR3 Slicer: QIDI Print and other third-party software, such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc. Operating System: Windows, MacOS, Linux Assembled: Assembled and First Print within 10 minutes
Weight & Size	Product Weight: 30.2kg Product Size(L x W x H): 553x553x601mm
